Product Name | MECHANIC DX-230 Multi-function Industrial Camera 2300W Pixels 1080P HDMI Microscope Camera USB HD Camera |
Item NO. | 1038355 |
Microscope parts | Microscope camera |
Weight | 0.51 kg = 1.1244 lb = 17.9897 oz |
Category | Phone repair tools > Microscope |
Tag | microscope camera , DX-230 , 230 , DX , industrial camera , HDMI camera , HD camera , USB camera |
Brand | MECHANIC |
Creation Time | 2020-04-13 |
Parameters :
Image Sensor:Panasonic original 23 million megapixel CMOS SensorSensitive size:1/2.3 inches, a larger field of view than the usual 1/3Cell size 1.335 ]um x 1.335 ]umOutput Interface: HDMK(TypeA)、USB(TypeB)、TFCard Photo resolution: 23MegaPixel, 23 million pixels Video resolution: 2K(30 frame)1080(60 frame)HDMI output:Progressive 1920*1080 60 frames Can be output simultaneously with USBHDMI output ratio Support 4:3,16:9,16:10 screen to ensure that the image is not deformed USB2.0 output (free drive):1920*1080 30 Frame 1280*720 30Frame 640M80 30F.Can be output slmultaoeously with HDMLTF card storage capacity: Up to 64GBWhite balance: One button white balance automatic / manual, R, G, B individually adjustableexposure: automatic / manual.Adjustable exposure valueCrosshair: 8 strip.Color, thickness, position adjustableCross Tick Line:2 strip with scaleCross dotted line:2 strip.Color, thickness, position adjustable Sharpness, contrast, saturation:Support, adjustable Black and white, negative:SupportMirror:Horizontal and vertical mirroringLanguage:Chinese /English Digital zoom:Supportremote control:Support:Remote video recording, the picture is not shakenInput voltage: DC 12V (support 5~19V)7 55-21 large interfacePower:0.15 watts maximum (12V, 0.12A) Lens interface:C/CS portnet weight: 180gGross weight: 400gProduct Size:73*73*30mmPackage dimensions:160*100+80mm
